پراخ شوی فلزي شیټ د لویې لارې پل کټاره
Anti-glare mesh is a kind of metal screen industry, also known as anti-throw net, which can effectively ensure the continuity and lateral visibility of anti-glare facilities, and can isolate the up and down lanes to achieve the purpose of anti-glare and isolation. Anti-throw net is a very effective highway guardrail product.
The anti-glare/anti-throw net is mostly made of welded steel mesh, special-shaped pipe, side ears, and round pipe, and the connecting accessories are fixed with the hot-plated pipe pillars. The anti-glare net/anti-glare net has excellent anti-glare performance, and is mostly used in highways, highways, railways, bridges, construction sites, communities, factories, airports, stadium green areas, etc. The anti-glare net plays a role in anti-glare and The role of protection.
1. The mesh is formed from a single piece of metal
2. The process is not wasteful of material
3. Higher strength-to-weight ratio than sheet metal
4. Anti-slip surface
5. Excludes and retains simultaneously
6. Premium reinforcement properties
7. Practical and effective screening
8. High efficient conductor
9. Super corrosion resistance
| ضخامت (ملي متره) | SWD (ملي میتر) | د LWD (ملي متره) | سټرینډ (ملي میتر) | پلنوالی (متر) | اوږدوالی (متر) | وزن (کیلوګرام/متر مربع) |
| 0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
| 0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
| 0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
| 0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
| 1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
| 1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
| 1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
| 1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
| 1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
| 1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
| 2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
| 2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
| 3 | 40 | 80 | 3.8 | 2 | 4 | 5.00 |
| 4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
| 4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
| 5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
| 6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
| 8 | 50 | 100 | 8 | 2 | 2.1 |
28.26 |
